Wired GPS Tracker GT04A | GREAT WILL
Great Will GT04A 4G series GPS tracker supports a voltage range of 9-90V and is suitable for a wide range of vehicle models. Thanks to its large built-in antenna and compact size, it enables faster and more accurate positioning and can be concealed for installation. In addition to its standard features, power-off and anti-tamper alarms provide theft deterrence.
- 9‒90V DC with overvoltage protection 180mA
- 3.7V industrial-grade Li-Polymer battery
- Multiple Alarm System
Multiple Positioning Modes，Low Consumption Working--GT04A
GT04A is a wired GPS tracker, is a reliable 4G LTE Cat1 GNSS network coverage. It is equipped with 9-90V wide voltage and has over voltage protection function. It supports real-time positioning kas well as dualIp blind spot compensation, allowing you to au mstorical traiectory playhack always know the vehicle trajectory
Remote Cut-Off (Fuel/Power)
Immobilize a vehicle by cuttingoffits fuel supply via aninstalledrelay.
Ignition Detection Vehicle
Constantly detect the Acc/ignitionstatus ofthe vehicle
Multiple Alerts
Instant alerts for atypical events such overspeed,ignition detection,collision,geo-febce entry/exit,etc
Technical Specifications
| Specification | GT04A |
| Network Frequency | LTE-FDD/LTE-TDD (9 Bands) |
| Working Voltage | DC 9V - 90V (with overvoltage protection) |
| Dimensions | 86mm * 43mm * 15mm |
| Location Accuracy |
< 2.0 meters CEP
|
| Positioning Way | GPS+GLONASS+GALILEO+BEIDOU+AGPS |
| Working Current |
<30mA @ 12V (Normal Mode)
|
| Standby Battery | 180mAh / 3.7V (approx. 17h standby) |
| Working Temperature |
-20°C to +75°C (-4°F to 167°F)
|
| Ingress Protection |
IP54
|
| G-sensor |
Built-in 3-axis accelerometer
|
| Memory | 4MB Internal Flash Memory |
| SIM Card Type |
Micro-SIM
|
Main Features
Real-time Tracking
Support 2 Servers
Cut Off Oil/Fuel
Geo-Fence
Voltage 9-90V
GT04A GPS Tracker Applicable Scenarios
Private Car Theft Prevention
Private Car Theft Prevention
Click HereFleet Management
Fleet Management
Click HereFinancial Lending
Financial Lending
Click HereBulk GPS Tracking Devices Ready-to-Ship
GREAT-WILL specializes in GPS tracker wholesale. We maintain a regular stock of market-proven devices to quickly fulfill orders for vehicle trackers, asset trackers, and heavy equipment monitors. We support OEM/ODM and customization services. Whether for your own business or for resale, the GT04A offers exceptional quality and value.
After-sales service and Warranty
- Provide after-sales technical support and product testing
- Continuously adjust products to suit local conditions and vehicles
- Warranty period up to 3 years
Delivery Time and Shipping
- Sample delivery time is approximately 3-5 days.
- Large-volume orders take over 7 days.
- The device/platform software/SIM/IoT card undergo engineering inspection and testing before packaging and shipment.
- Multiple shipping methods supported.
GT04A 4G GPS tracker is suitable for the following scenarios
Overspeed Detection: Equipped with an overspeed alarm function, the tracker will issue a speeding alert when the vehicle speed exceeds the maximum speed limit set by the platform. This is suitable for private car drivers, taxi drivers, and ride-hailing drivers, improving vehicle and driver safety.
Power Unplug Detection: GT04A 4G vehicle-mounted GPS tracking terminal will issue a power outage alert if it detects that the vehicle voltage has dropped below a certain level or the power cord has been unplugged. The GT04A has a backup battery and an operating voltage of 9-90V DC, providing the necessary power status detection.
Tow Detection: 4G GPS tracker can detect whether a vehicle is being towed by using displacement changes and other methods.
Collision Detection: GPS trackers can implement collision warnings by adding an accelerometer. The GT04A, with its vibration sensor or alarm system, can provide a certain degree of collision detection.
